TY0015C01 Ignition System Spark Plug Wire Connector For Auto Engine
  • name
  • name

TY0015C01 Ignition System Spark Plug Wire Connector For Auto Engine

MOQ: 1000pcs
Price: negotiation
Standard Packaging: Carton size：400*300*155mm Single carton volume：0.0186m3 Package quantity：540Pcs N.W：9KG；G.W：10KG
Delivery Period: 15 working days after received your payment
Payment Method: T/T or western Union
Supply Capacity: 200,000 pcs per month
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
TY
Certification
ISO/TS16949:2009
Model Number
TY0015C01
Product Name:
Spark Plug Connector/plug/boiler Connector
Product Value:
5KΩ±20%
Appearance:
Assembly Parts
Standard:
ISO6856/ISO3808
Application:
High Voltage Ignition System
Withstand Voltage:
≥30KV
Feature:
High And Low Temperature Resistance, With Damping
Customers:
BorgWarner、JANMOR Etc.
Highlight:

Spark Plug Wire Connector

,

Ignition Coil Connector

,

Odorless Spark Plug Wire Connector

Product Description

High Voltage Ignition System Spark Plug Wire Connector for Auto Engine





Specifications:



Raw material properties

Shore-A hardness

55±5A

Elongation at break

≥300%

Tear strength

≥15N/mm

Dielectric strength

≥20KV/mm

Tensile strength

≥6N/mm2

Tensile deformation

≤20%

Density

1.17±0.02 g/cm3

Withstand voltage 18KV for 30minutes

NO breakdown

Surface resistance

≥1011Ω

Ageing resistance

155±2.5℃X168h,Without any cracking (155±2.5℃X168h

Product characteristics

Usage temperature

-20℃-155℃

Breakdown voltage (AC)

≥30KV

Insertion and removal forces

20-70N

Overall length

113.5+3-6 mm

Resistance

5KΩ±20%

Assembly dimension

Cable entry diameter

6±0.5mm

Assembly dimension: connecting cable

TY0015C01 Ignition System Spark Plug Wire Connector For Auto Engine 0

Plug entry diameter

11±0.5mm

Assembly dimension: connecting spark plug

TY0015C01 Ignition System Spark Plug Wire Connector For Auto Engine 1




Description:

  1. The spark plug connector has great heat resistance, cold tolerance, and dielectric properties
  2. Silicone rubber is colorless and odorless.
  3. The shied of the product owns a smooth surface. Logo can be added according to the customer.
  4. Can prevent electromagnetic interference
  5. Usage temperature is -20~155℃
  6. No transformation, heat resistance, acid and alkali resistance, no dilatation
  7. Service life of the connector is not less than 50,000 km or 3 years
  8. Can be designed and developed according to customer’s requirements



Applications:

  1. This spark plug connector is used in the ignition system of auto engine

TY0015C01 Ignition System Spark Plug Wire Connector For Auto Engine 2
