Automobile Ignition System High Temperature Spark Plug Boot Heat Shield

Automobile Ignition System High Temperature Spark Plug Boot Heat Shield

  • High Light

    Rubber Spark Plug Boot

    ,

    Spark Plug Components

  • Color
    Black
  • Shape
    Straight
  • Material
    Silicone Rubber
  • Feature
    High Voltage Resistance
  • Application
    Auto Engine
  • Customers
    JANMOR Etc.
  • Place of Origin
    CHINA
  • Brand Name
    TY
  • Certification
    ISO/TS 16949: 2009
  • Model Number
    TY0009B02
  • Minimum Order Quantity
    1000
  • Price
    Negotiation
  • Packaging Details
    Based on customer's demand
  • Delivery Time
    15 working days after receviced your payment
  • Payment Terms
    T/T, Western Union
  • Supply Ability
    200,000pcs per month

Automobile Ignition System High Temperature Spark Plug Boot Heat Shield

Automobile Silicone Rubber Boot , conneting Spark Plug ,  High / Low Temperature Tolerance





Applications:

  1. used in auto engine, a high voltage ignition system



Strength of product:

  1. Product has no smell, health for people.
  2. Great heat resistance, cold tolerance, and dielectric properties
  3. Long life: be able to use no less than 50,000 km or 3 years
  4. Based on complete die processing equipments, sheaths can be designed and developed according to customer’s requirements in a short time.



Product Basic features:

  • Color: Black
  • Material: Silicone rubber
  • Withstand voltage: ≥30KV
  • Usage temperature: -20℃-155℃
  • Burr of the parting lines: ≤0.5mm
  • Inner diameter: φ15±0.5mm
  • External diameter: φ34±0.5mm, φ35.5±0.5mm (max)



Properties of raw material:

  • Shore-A hardness: 55±5A
  • Elongation at break: ≥300%
  • Tear strength: ≥15N/mm
  • Dielectric strength: ≥20KV/mm
  • Tensile strength: ≥6N/mm2
  • Tensile deformation: ≤20%
  • Density: 1.17±0.02 g/cm3
  • Withstand voltage 18KV for 30minutes: NO breakdown
  • Surface resistance: ≥1011Ω
  • Ageing resistance: 155±2.5℃X168h,Without any cracking
