Stable Resistor Spark Plug Caps With No Resistance But Galvanical ≥30KV

Large Image : Stable Resistor Spark Plug Caps With No Resistance But Galvanical ≥30KV

Product Details:

Place of Origin:	CHINA
Brand Name:	TY
Certification:	ISO/TS 16949: 2009
Model Number:	TY0046B04

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pcs
Price:	negotiation
Packaging Details:	Based on customer's demand
Delivery Time:	15 working days after payment
Payment Terms:	T/T, Western Union
Supply Ability:	250,000 pcs per month

Contact Now

Stable Resistor Spark Plug Caps With No Resistance But Galvanical ≥30KV

Description

Color:

Black

Resistance:

Usage Tem Range:

-20℃~155℃

Customers:

BorgWarner, JANMOR Etc.

High Light:

Resistor Type Spark Plugs

Resistor Spark Plug

Stable and Durable PPS Spark Plug Resistor with no Resistance but Galvanical

Strength of product:

Short-term heat resistance and long-term thermal stability are both better than any other current engineering plastics.
Great dimension stability under the condition of high temperature and high humidity
High mechanical strength but low abrasion
No deformation, heat resistance, acid and alkali resistance, no dilatation
Useful time is not less than 50,000 km or 3 years
Can be designed and developed according to customer’s requirements

Product basic characteristics:

Resistance	0
Color	Black
Withstand voltage	≥30KV
Usage temperature	-20-155℃
Insertion and Removal forces	20N-70N
Material	PPS(Black)
Assembly way	Injection molding
Assembly dimension: connecting ignition wire
Assembly dimension: connecting Spark Plug

Material properties of product:

Melting point	≥280℃
Heat distortion temperature	≥260℃
Luo's hardness	＞100HR
Tensile strength	＞170Mpa
Bending strength	＞220Mpa
Notched impact strength	＞16Mpa
Bending modulus	＞3.5x10⁴
Molding shrinkage rate	＜0.0025%
Absorptivity	＜0.05%
Surface resistivity	≥1.0 X 10¹⁵Ω
Volume resistivity	≥1.0 X 10¹⁶Ω.m
Electrical strength	＞18KV/m
Friction coefficient	0.01-0.02

Applications:

Used in the ignition system of auto engine
