0 KΩ Plastic Straight Spark Plug Cap Resistor Heat Resistance and Thermal Stability

Large Image : 0 KΩ Plastic Straight Spark Plug Cap Resistor Heat Resistance and Thermal Stability

Product Details:

Place of Origin:	CHINA
Brand Name:	TY
Certification:	ISO/TS 16949: 2009
Model Number:	TY0034B04

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pcs
Price:	negotiation
Packaging Details:	Based on customer's demand
Delivery Time:	15 working days after payment
Payment Terms:	T/T, Western Union
Supply Ability:	250,000 pcs per month

Contact Now

0 KΩ Plastic Straight Spark Plug Cap Resistor Heat Resistance and Thermal Stability

Description

Material:	PPS	Color:	Black
Resistance:	0	Customers:	BorgWarner, JAMMOR Etc.
Application:	High Voltage Ignition System	Standard:	ISO 6856 / ISO 3808
Highlight:	Spark Plug Resistance , Resistor Spark Plug

0 KΩ Plastic Straight Resistor with excellent Heat Resistance and Thermal Stability

1. Resistor Description:

Short-term heat resistance and long-term thermal stability are both better than any other current engineering plastics.
Great dimension stability under the condition of high temperature and high humidity
High mechanical strength but low abrasion
No deformation, heat resistance, acid and alkali resistance, no dilatation
Useful time is not less than 50,000 km or 3 years

2. Resistor Specifications

Raw material properties	Melting point	≥280
	Heat distortion temperature (℃)	≥260
	Luo's hardness (HR)	＞100
	Tensile strength (Mpa)	＞170
	Bending strength (Mpa)	＞220
	Notched impact strength (Mpa)	＞16
	Bending modulus	＞3.5x10⁴
	Molding shrinkage rate (%)	＜0.0025
	Absorptivity (%)	＜0.05
	Surface resistivity (Ω)	≥1.0 X 10¹⁵
	Volume resistivity (Ω.m)	≥1.0 X 10¹⁶
	Electrical strength (KV/m)	＞18
	Friction coefficient	0.01-0.02
Product characteristics	Resistance (KΩ)	0
	Color	Black
	Withstand voltage (KV)	≥30
	Usage temperature (℃)	-20-155
	Insertion and Removal forces (N)	20N-70N
	Material	PPS
	Assembly way	Injection molding
	Assembly dimension: connecting ignition wire
	Assembly dimension: connecting Spark Plug

3. Applications:

Used in the ignition system of auto engine

4. Competitive advantage:

Own CNC maching center, electrical discharging machine and other processed equipments
Be able to produce modes by ourselves, so can design and develop specific products for customers, meet special requirements.
